Soundproof sandwich panel

Bona is a clean room panel, door and window manufacturer in China supplying construction materials for clean room projects.

A shipment of 100 mm thickness 120 kg density soundproof rock wool sandwich panel wall has been made to Indonesia. This project has a requirement specially on sound reduction, rock wool is a suitable insulation panel option based on its superior sound proof performance and besides it has a good performance on fire resistance.

Soundproof sandwich panel specification

Product name	Soundproof sandwich panel
Panel width	1150 mm
Panel length	as project need
Panel thickness	50/75/100 mm
Core insulation	Rock wool
Rock wool density	60/80/100/120 kg/m3
Panel color	off white or as request
Minimal quantity	300 SQM
Lead time	within 7 days
Packing way	in bulk or wooden pallet
Application	clean room wall, clean room ceiling, walls for prefabricated house, steel structure warehouse

ASK A QUOTE

Soundproof sandwich panel characteristics

The soundproof rock wool sandwich panel is an solution for noise reduction in buildings. Made with high-quality rock wool insulation, it effectively absorbs sound waves and reduces noise pollution. Its durable and fire-resistant properties make it an ideal choice for both residential and commercial applications.

Rock wool is a fibrous material made by melting natural rocks (such as basalt) at high temperatures, forming a large number of irregular porous structures inside (with a porosity of over 90%). When sound waves enter the interior of rock wool, they cause air molecules in the pores to vibrate.

Due to the friction and viscous resistance between air and fibers, the energy of sound waves is converted into heat energy for consumption, thereby reducing the reflection and transmission of sound energy and achieving sound absorption and noise reduction.

The performance of the soundproof sandwich panel is directly related to the density and thickness of rock wool. The highest sound absorption coefficient is achieved at medium density of rock wool (such as 100-150 kg/m ³).

For every 50 mm increase in thickness of the soundproof sandwich panel, the sound insulation can be improved by about 3-5 dB. For example, a 50 mm thick rock wool sandwich panel has a sound insulation of about 25-30 dB, and a 100 mm thick rockwool sandwich panel can reach 35-40 dB (equivalent to the level of "normal conversation sound" reduced to "soft whispers").

Panel Thickness (mm)	Rock Wool Density (kg/m³)	Sound Insulation Rw
50 mm	100 kg/m³	28-32 dB
75 mm	120 kg/m³	32-35 dB
100 mm	150 kg/m³	35-40 dB

The sound insulation level of a regular 240 mm brick wall is about 45 dB, while soundproof sandwich panel of rock wool can approach the sound insulation level of traditional walls by increasing thickness and density.

ASK A QUOTE

Soundproof sandwich panel application

Industrial buildings: soundproof sandwich panel of rock wool is used for walls or partitions in factory buildings to block the mechanical noise and improve the workshop environment.

Public buildings: It is suitable for school classrooms, hospital wards, conference rooms, etc., to reduce the interference of corridor voices and outdoor traffic noise.

Civil buildings: soundproof sandwich panel of rock wool is used as partition walls or exterior walls in prefabricated buildings to reduce neighborhood noise.
